awwac210 liquid epoxy coated steel pipe and supply
1.Description
Pipe Type |
Seamless Steel Pipe/ Welded Pipe/ SSAW pipe / LSAW Pipes |
Epoxy Coating Thickness |
50 um to 1200um |
Pipe Material |
ASTMA53/ASTMA106/API 5L GR.B , X42,X52,X60 ect |
Pipe Length |
1m to 50m |
Pipe End |
Plain End, Bevel End, Groove End , NPT thread and coulpings |
Surface treatment |
sand blasting , Sa2.5, Sa3.0,free of oil , rust , |
Pipe Sizes |
internally epoxy coated : >DN100
externally epoxy coated :>DN20 |
Wall thickness |
sch40, sch60, std,sch80, sch100,sch160 |
Package |
Bundle package |
Shipment |
in 20FT, 40FT container or break bulk vessels |
Production Capacity |
10000 tons per month . |
2. Coating Production Range
For the internal and external coating, we mainly make the followings according to the international standards . We are also willing to make the coating for he specified customers as their request in order to expand market share and improve our production level.
Internal Coating:
Liquid Epoxy Coating |
AWWA C210-2007 |
FBE |
AWWA C 213-2001 |
Cement Mortar Lining |
BS 534-1990,AWWA C205-2001 |
Bitumen Coating |
BS 534-1990 |
External Coating :
Coating Type |
Coating Standard |
3LPE/3LPP Coating |
DIN 30670-1991, CAN/CSA Z245.21-2010,ISO 21809-1-2009
SY/T 0413-2002, GB/T 23257-2009 |
2LPE/2LPP Coating |
SY/T 0413-2002, GB/T 23257-2009, ISO 21809-1-2009 |
(Fusion- Bond Epoxy)FBE |
SY/T 0315-2005, AWWA C 213-2001, CAN/CSA Z245.20-2010, ISO 21809-2-2007, API RP 5L9-2001 |
Bitumen coating /Enamel & tape hot-applied |
BS 534-1990,AWWA 203-2002,AWWA 214-2000 |
Liquid Epoxy Coating |
AWWA C210-2007 |
Polyurethane Insulated Coating |
SY/T 0415-1996, CJ/T 114-2000, EN 253-1994 |
3.Epoxy Production Flow Chart

4. Sand blasting.
To ensure coating quality , pipe will do sand blasting to Sa2.5 or Sa3.0 grade level .

5. Inspections of epoxy coatings
To ensure coating quality , we will do test as per ITP documents and standard request , like Peel test , holiday test , pull-off test , hardness test and bend test .

6. Epoxy for pipes fittings – Y tee, bend , elbows ect :

7. One Stop- Purchase Service :
Except for anti corrosive coated steel pipes and pipe fittings, Decho can also provide you steel bars, steel plates, steel coils, galvanized pipes, oval pipes ,square pipes, as well as flanges. If you have any request for your project ,pls do not hesitate to contact us by email : [email protected]
